At MyTankFarm we carry a wide selection of used and unused stainless steel tanks ranging from 400 gallons up to 500 gallons on this page. You will find vacuum tanks, jacketed pressure vessels, storage tanks, mixing tanks, cone bottom, dished bottom and many other styles from various top of the line manufacturers such as Letco, Feldmeier, Precision, Bendel, Air Flow, Allegheny Bradford, Mueller, Rubicon, Letsch, Whiting and many many more. These used pressure vessels and storage tanks are ideal for the manufacturing of bio diesel, ethanol, food processing, pharmaceutical and other manufactures.

Description

1.

Stainless Steel Tanks: Used 400 gallon vertical stainless steel flat bottom tank
Used 400 gallon vertical stainless steel tank. The tank diameter is 46", the overall height is 82", and the straight side height is 60". The tank top has a 1.5" NPT inlet, a 1" NPT inlet, and a 12" x 12" opening. The tank side has a 3" flange on top of side, a 2" flange on top of side, and a 2" NPT on top of side. The tank’s flat bottom has a 6.25" diameter flanged center discharge.
Item No. MTF02012-6033

2.

Stainless Steel Tanks: Used 400 gallon vertical stainless steel cone bottom storage tank
Used approximately 400 gallon stainless steel vertical insulated storage tank. 49" diameter X 48" high straight side. Flat welded top, cone bottom. Top fittings: 1/3 hinged lid, (1) 1", (1) 2", (1) 3", (1) 4", and (1) 5' center opening. 4" center bottom drain. (1) 3" side bottom outlet and (1) 6" side top inlet. Mounted on (4) carbon steel legs, giving 27" clearance. (2) IN STOCK
Item No. MTF02097-0008

3.

Stainless Steel Tanks: Used 450 gallon 304 vertical stainless steel tank, cone bottom
Used approximately 450 gallon 304 stainless steel vertical storage tank. 45.75" diameter X 60" high straight side. Cone top and bottom. Top fittings: (1) 1 1/2" NPT and (1)1/2" NPT. 2" NPT center bottom drain. 3/4" NPT side top inlet and (2) 1 1/2" NPT side inlets for level indicator. 16" side bottom manway. Mounted on (4) carbon steel legs giving 16" clearance from the bottom outlet face.
Item No. MTF02105-0003

4.

Stainless Steel Tanks: Used 450 gallon vertical 304 stainless steel storage tank, cone bottom
Used approximately 450 gallon 304 stainless steel vertical storage tank. 45.75" diameter X 60" high straight side. Cone top and bottom. Top fittings: (1) 1 1/2" NPT and (1)1/2" NPT. 2" NPT center bottom drain. 3/4" NPT side top inlet and (2) 1 1/2" NPT side inlets for level indicator. 16" side bottom manway. Mounted on (4) carbon steel legs giving 16" clearance from the bottom outlet face.
Item No. MTF02105-0004

5.

Stainless Steel Tanks: Used Central Fabricators 500 gallon vertical stainless steel dimple jacketed conical bottom tank.
Used Central Fabricators Inc. 500 gallon vertical stainless steel tank with dimple jacketed conical bottom. National Board # 650. This tank has a dome top and a dimple jacketed conical bottom. The jacket has a 90 psi @ 330° F Working Pressure. The diameter is 40", the overall height is 108", the straight side height is 84" the dome top is 10" and the conical bottom is 12". The top has a 6.25" flange inlet. The side has (3) 2.5" flange inlets. The bottom has a 2.5" flange center discharge.
Item No. MTF02012-5994

6.

Stainless Steel Tanks:Used 500 gallon vertical 304 stainless steel pressure tank
Used Industrial Sheet Metal Works approximately 500 gallon vertical 304 stainless steel pressure tank. 48" diameter X 60" high straight side. Internal rated 35 PSI @ 200 degrees F. Welded dished heads. National Board# 314, S/N 19383-3. Top fittings: (4) 4", (1) 8" and (1) 2". 1" center bottom drain. Mounted on carbon steel legs giving 23" clearance to floor (2) IN STOCK
Item No. MTF0515-0006

All prices in US Dollars
